| Chipset |
Intel H610 |
| CPU SUPPORT |
Support for 12th/13th/14th Generation Intel Core™ i9/ i7/ i5/ i3 processors and Intel Pentium processors/ Intel® Celeron processors in the LGA1700 package
* Please refer to www.biostar.com.tw for CPU support list. |
| MEMORY |
12th Gen Intel Core CPU
Supports Dual Channel DDR5 up to 4800
14th & 13th Gen Intel Core CPU
Supports Dual Channel DDR5 up to 5600
2 x DDR5 DIMM Memory Slot, Max. Supports up to 96 GB Memory
Each DIMM supports non-ECC 8/ 16/ 24/ 32/ 48 GB DDR5 module
Support Intel® Extreme Memory Profile (XMP) memory modules
* Please refer to www.biostar.com.tw for Memory support list.
** The actual frequency is may depend on CPU. |
| INTEGRATED VIDEO |
Supports DX12
Supports HDCP |
| STORAGE |
Total supports 1 x M.2 socket and 4x SATA III (6Gb/s) ports
Intel H610 Chipset
1 x M.2 (M Key) Socket (M2_PCIEG3_32G_SATA):
Supports M.2 Type 2242 /2260 /2280 SSD module
Supports PCI-E 3.0 x4 (32Gb/s) - NVMe/ AHCI SSD & SATA SSD
4 x SATA III Connector (6Gb/s)
* Specifications vary by CPU types |
| LAN |
Intel I219V
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability |
| AUDIO CODEC |
ALC897
7.1 Channels, High Definition Audio |
| USB |
4 x USB 3.2 (Gen1) port (2 on rear I/Os and 2 via internal headers)
8 x USB 2.0 port (4 on rear I/Os and 4 via internal headers) |
| EXPANSION SLOT |
INTEL 12th/13th/14th Processors
1 x PCIe 4.0 x16 Slot
Intel H610 Chipset
1 x PCIe 3.0 x1 Slot
* Specifications vary by CPU types |
| REAR I/O |
1 x PS/2 Keyboard/ Mouse Port
1 x HDMI
1 x VGA Port
2 x USB 3.2 (Gen1) ports
4 x USB 2.0 ports
1 x LAN port
3 x Audio Jack |
| INTERNAL I/O |
4 x SATA III Connectors (6Gb/s)
2 x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
1 x 8-Pin Power Connector
1 x 24-Pin Power Connector
1 x CPU Fan Connector
1 x System Fan Connector
1 x Front Panel Header
1 x Front Audio Header
1 x Internal Stereo Speaker Header
1 x Clear CMOS Header
1 x COM Port Header
1 x TPM Header |
| H/W MONITORING |
CPU / System Temperature Monitoring
CPU / System Fan Monitoring
Smart / Manual CPU Fan Control
CPU/DDR Voltage Monitoring |
| DIMENSION |
Micro ATX Form Factor Dimension: 20.8cm x 23.6cm ( W x L ) |
| OS SUPPORT |
Supports Windows 10 (64bit) / 11(64bit)
※Biostar reserves the right to add or remove support for any OS with or without notice. |
| BUNDLE SOFTWARE |
BullGuard |
| ACCESSORIES |
2 x SATA Cable
1 x I/O Shield
1 x DVD Driver
1 x Quick Guide |
